Imix Viper 90: Bee Eye Moving Head Beam Light
R2 350,00
Imix Viper 90: Bee Eye Moving Head Beam Light
Professional 6×15W LED with Ring Wash – DMX512 Control
| Weight | 4,1 kg |
|---|---|
| Dimensions | 31,5 × 27,5 × 22,5 cm |
| Light Configuration |
6 x LEDS |
| Light Type |
Beam |
| Power Rating |
15W |
Additional Information
| Attribute | Value |
|---|---|
| Light Configuration | 6 x LEDS |
| Light Type | Beam |
| Power Rating | 15W |
In stock
The IMIX Viper 90 is a high-performance moving head beam light featuring a 6×15W RGBW “Bee Eye” LED and an LED ring wash for dynamic stage effects. With 540° pan / 270° tilt, 4° ultra-narrow beam, and 150mW green laser, it delivers sharp beams, vibrant colors, and atmospheric washes—perfect for concerts, clubs, and events.
Key Features
✔ 6×15W RGBW “Bee Eye” LED – High-intensity, smooth color mixing
✔ LED Ring Wash – Adds ambient wash effects (7 colors + strobe)
✔ 150mW Green Laser – Eye-catching beam enhancement
✔ 540° Pan / 270° Tilt – Full-range movement with 8/16-bit precision
✔ 4° Ultra-Narrow Beam – Piercing aerial effects
✔ DMX512 (17CH) Control – Professional lighting integration
✔ Multiple Modes – Auto, Master/Slave, Sound-Activated, DMX
Technical Specifications
Lighting Performance
LEDs: 6 × 15W RGBW (4-in-1) + LED ring wash
Laser: 150mW green (0-100% dimmable)
Beam Angle: 4° (ultra-narrow)
Color Mixing: 16.7 million colors + rainbow effects
Dimming & Strobe: 0-100% linear, 1-20Hz strobe
Movement & Control
Pan/Tilt: 540° / 270° (adjustable speed)
Scan Modes: 8/16-bit fine-tuning, auto-calibration
DMX Channels: 17CH (full parameter control)
Control Modes: DMX512, Auto, Master/Slave, Sound-Activated
Power & Build
Voltage: AC 100-240V, 50/60Hz
Power Consumption: 80W
Cooling: Heat sink + fan (intelligent temp control)
Weight: 4 kg | Size: 26 × 18 × 30 cm
Safety & Usage Notes
⚠ Indoor Use Only – Not waterproof (avoid humidity/water)
⚠ Eye Safety – Avoid direct long-term exposure to beams/laser
⚠ Installation – Ensure proper ventilation and secure mounting
⚠ Voltage: Use only 100-240V power sources
DMX Channel Table (17CH Mode)
| CH | Function | DMX Value | Effect |
|---|---|---|---|
| 1 | X-Axis (Pan) | 000-255 | 0°–540° movement |
| 2 | X-Axis Fine-Tune | 000-255 | Precision adjustment |
| 3 | Y-Axis (Tilt) | 000-255 | 0°–270° movement |
| 4 | Y-Axis Fine-Tune | 000-255 | Precision adjustment |
| 5 | Pan/Tilt Speed | 000-255 | Slow → Fast |
| 6 | Bee Eye Motor | 0-127: 0-360° position | 128-255: Clockwise/CCW spin |
| 7 | Master Dimming | 000-255 | 0-100% brightness |
| 8 | Strobe | 010-255 | 1-20Hz strobe |
| 9-12 | Bee Eye RGBW Dimming | 000-255 | Individual color control |
| 13 | Laser Dimming | 000-255 | 0-100% intensity |
| 14-16 | LED Ring Wash Color/Speed | 013-255 | 7 colors + speed control |
| 17 | Reset/Macro | 000-255 | Auto-effects & sound response |
